ชื่อสินค้า

DS-2CD2325FHWD-I

รายละเอียดสินค้า

2 MP High Frame Rate Fixed Turret Network Camera

กล้องวงจรปิด HikVision รุ่น DS-2CD2325FHWD-I สามารถนำมาติดตั้งใช้งานได้ทั้งภายในและภายนอกอาคาร โดยมีความละเอียดภาพอยู่ที่ 2 MP เพิ่มประสิทธภาพการทำงานด้วยเทคโนโลยี DarkFighter สามารถถ่ายภาพในพื้นที่แสงน้อยได้อย่างคมชัด เทคโนโลยีการบีบอัด H.265+ ช่วยประหยัดพื้นที่จัดเกบ็บได้ เทคโนโลยี True WDR ที่ช่วยตัดแสงจ้าได้ดีเยี่ยม และสามารถกันน้ำ กันฝุ่น (IP67) ได้อีกด้วย

คุณสมบัติ

  • High quality imaging with 2 MP resolution
  • Excellent low-light performance via powered-by-DarkFighter technology
  • Efficient H.265+ compression technology
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • High frame rate video to illustrate smooth movement
  • Water and dust resistant (IP67)
  • Robust structure design with full metal materials.

ข้อมูลจำเพาะ

Camera
Image Sensor1/2.8" Progressive Scan CMOS
Min. Illumination       Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR,Color: 0.009 lux @(F1.6, AGC ON), 0 lux with IR
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Wide Dynamic Range120dB
Day & NightIR Cut Filter
Angle Adjustment          Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
FocusFixed
Lens Type         2.8/4/6/8/12 mm
FOV     2.8 mm, horizontal field of view: 108°;4 mm, horizontal field of view: 86.4°;6 mm, horizontal field of view: 52°;8 mm, horizontal field of view: 41°;12 mm, horizontal field of view: 25°
ApertureF1.6
Lens MountM12
Illuminator
IR Range          Up to 30 m
Wavelength850nm
Video
Max. Resolution1920 × 1080
Main Stream50Hz: 50fps (1920 × 1080, 1280 × 960, 1280×720);60Hz: 60fps (1920 × 1080, 1280 × 960, 1280×720)
Sub Stream       50Hz: 25fps (640 × 480, 640 × 360, 320 × 240);60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288); 60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240)
Video CompressionMain stream: H.265/H.264; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264
Video Bit Rate   32 Kbps to 16 Mbps
H.264 Type       Main Profile/High Profile
H.265 Type                   Main Profile
H.264+Main stream supports
H.265+Main stream supports
Region of Interest (ROI)Support 1 fixed region for main stream and sub-stream separately
Network
Simultaneous Live ViewUp to 6 channels
API                  ONVIF (PROFILE S, PROFILE G), ISAPI
ProtocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
User/Host          Up to 32 users,3 levels: Administrator, Operator and User
SecurityPassword protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network StorageSupport Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR
ClientiVMS-4200, Hik-Connect, Hik-Central
Web BrowserPlug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local Service: Chrome 41.0+, Firefox 30.0+
Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error, PIR, illegal login
Day/Night SwitchDay/Night/Auto/Schedule
DNR    3D DNR
Image EnhancementBLC/3D DNR/HLC
Image Settings   Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Interface
On-Board Storage                      Built-in microSD/SDHC/SDXC slot, up to 128 GB
Hardware ResetYes
Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
Event
Basic Event       Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart EventLine crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection
Face DetectionYes
Exception Detection       Scene change detection
General
Firmware Version                      V5.5.80
Linkage MethodTrigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Web Client Language32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
General FunctionAnti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
Startup and Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply12 VDC ± 25%, 6 W, PoE(802.3af,  36 V to 57 V, class 3), 7 W
Camera Dimension        Camera: Φ 127.3 × 95.9 mm (5.01″ × 3.78″); Package: 150 × 150 × 141 mm (5.91″ × 5.91″ × 5.55″)
Camera WeightCamera: 620 g (1.37 lb.)
Approval
ProtectionIK10, IP66

ดาวน์โหลดข้อมูลเพิ่มเติม

ดาวน์โหลดแคตตาล็อก

ดาวน์โหลดคู่มือ
